Specifications
Model
MDV-
D90Q4/N1-D
MDV-
D100Q4/N1-D
MDV-
D112Q4/N1-D
MDV-
D140Q4/N1-D
Power supply
1 phase, 220-240V, 50Hz
Cooling
Capacity
kW
9
10
11.2
14
Input
W
160
160
160
170
Rated current
A
0.73
0.73
0.73
0.82
Heating
Capacity
kW
10
11.1
12.5
15
Input
W
160
160
160
170
Rated current
A
0.73
0.73
0.73
0.82
Indoor fan motor
Model
YDK90-6E-1
Type
AC
Input (H/M/L)
W
143/114/93
143/114/93
143/114/93
148/116/96
Capacitor
uF
3.5
3.5
3.5
4
Speed (H/M/L)
r/min
770/640/550
770/640/550
770/640/550
820/750/620
Indoor coil
Number of rows
2
2
2
3
Tube pitch(a) × row
pitch(b)
mm
21×13.37
Fin spacing
mm
1.5
Fin type
Hydrophilic Aluminum
Tube outside dia.
and type
mm
Ф7, Inner groove Tube
Coil length × height
× width
mm
1955×252×26.74
1955×252×26.74
1955×252×26.74
1955×252×40.11
Number of circuits
8
8
8
12
Indoor air flow (H/M/L)
m
3
/h
1540/1300/1120
1540/1300/1120
1540/1300/1120
1800/1500/1280
Sound pressure level (H/M/L)
dB(A)
48/45/43
48/45/43
48/45/43
50/47/44
Indoor unit
Dimension
(W × H × D)
mm
904×300×840
Packing
(W × H × D)
mm
955×330×955
Net/Gross weight
kg
32/37
Panel
Dimension
(W × H × D)
mm
950×54.5×950
Packing
(W × H × D)
mm
1035×90×1035
Net/Gross weight
kg
6/9
Refrigerant type
R410A
Throttle
Type
Electronic expansion valve
Design pressure(H/L)
MPa
4.4/2.6
Pipe connections
Liquid pipe
mm
Φ9.53
Gas pipe
mm
Φ15.9
Drain pipe
mm
ODФ32
Controller
Wireless remote controller
Notes:
1. Nominal cooling capacities are based on the following conditions: return air temperature.: 27°CDB, 19°CWB, and outdoor
temperature:35°CDB, equivalent ref. piping: 7.5m (horizontal)
2. Nominal heating capacities are based on the following conditions: return air temperature: 20°CDB, outdoor t temperature:
7°CDB, 6°CWB, and equivalent ref. Piping: 7.5m (horizontal)

Midea One-way Cassette Series Specifications
