Midea One-way Cassette Series

One-way Cassette MCAC-VTSM-2017-01
5
Specifications
Model
MDV-D45Q1/N1-D
MDV-D56Q1/N1-D
MDV-D71Q1/N1-D
Power supply
1 phase, 220-240V, 50Hz
Cooling
Capacity
kW
4.5
5.6
7.1
Input
W
48
48
60
Rated current
A
0.27
0.32
0.36
Heating
Capacity
kW
5
6.3
8
Input
W
43
44
55
Rated current
A
0.27
0.32
0.36
Indoor fan motor
Model
YDK38-4
YDK43-4
Type
AC
Input(H/M/L)
W
39.5/33.5/25.6
41.5/36.0/28.0
56.2/40.2/28.7
Capacitor
μF
1.5
3
3
Speed (H/M/L)
r/min
930/830/710
1080/990/860
1150/1020/850
Indoor coil
Number of rows
2
Tube pitch(a) × row pitch(b)
mm
21×13.37
Fin spacing
mm
1.5
Fin type
Hydrophilic aluminum
Tube outside dia. and type
mm
Ф7 Inner groove tube
Coil length × height × width
mm
955×231×26.74
955×336×26.74
Number of circuits
3
3
5
Indoor air flow (H/M/L)
m
3
/h
693/600/476
792/688/549
933/749/592
Sound pressure level (H/M/L)
dB(A)
41/39/35
42/40/36
44/41/37
Indoor unit
Dimension (W×H×D)
mm
1275×189×450
Packing (W×H×D)
mm
1370×295×505
Net/Gross weight
kg
18.5/22.8
18.8/23.1
19.5/23.8
Panel
Dimension (W×H×D)
mm
1350×25×505
Packing (W×H×D)
mm
1410×95×560
Net/Gross weight
kg
4/5.4
Refrigerant type
R410A
Throttle
Type
Electronic expansion valve
Design pressure(H/L)
MPa
4.4/2.6
Pipe connections
Liquid pipe
mm
Ф6.35
Ф9.53
Ф9.53
Gas pipe
mm
Ф12.7
Ф15.9
Ф15.9
Drain pipe
mm
ODФ25
Standard Controller
Wireless remote controller
Notes: 1. Nominal cooling capacities are based on the following conditions: return air temperature: 27°CDB,19°CWB,
outdoor temperature:35°CDB,equivalent ref. Piping: 7.5m(horizontal)
2. Nominal heating capacities are based on the following conditions: return air temperature: 20°CDB,outdoor
temperature: 7°CDB,6°CWB,equivalent ref. Piping: 7.5m(horizontal)
