Midea TempMaker Series User Manual

MCAC-UTSM-2014-03 R410A 380~415V 3Ph 50Hz TempMaker Series Split AC
132
3. Centralized Controller: MD-CCM03(A) (Optional)
3.1 Centralized controller specifications
Model
MD-CCM03(A)
Power Supply Voltage
220~240V 50Hz 1Ph
Ambient Temperature Range
-15°C ～43°C
Ambient Humidity Range
RH40%~RH90%
Performance Features
1. System composition, centralized control.
2. Keywords and general function description.
3. Technical indices and requirements.
4. Indoor unit working status display.
5. Locking remote controller, locking keyboard of centralized controller and locking running
mode.
3.2 Keypad of centralized controller
1) LOCK: In the mode setting mode, press the lock key, and the remote controller of the
currently selected air conditioner will be locked or unlocked. The operation mode is: If the
