5. Nomenclature
5.1 Main unit
MDV S – 252 (8) W / D R N1
5.2 Indoor unit
MDV – D 28 Z / D D V N1 A
Meaning of the code*
Type code
Meanings
Type code
Meanings
Q1
One way cassette
T3
Low static pressure duct
Q2
Two way cassette
G
Wall mounted
Q4
Four way cassette
DL
Ceiling & floor
Q4-A
Four way cassette (compact)
Z-F
Floor standing (F4/F5: Exposed ; F3: Concealed)
T1
High static pressure duct
Z
Console
T2
Medium static Pressure duct
T1-FA
Fresh air processing unit
Refrigerant type
N1:R410A Omit for R22
Power Supply
R: 380~415V, 50Hz, 3N
Inverter Type
D:DC Inverter Omit for AC Inverter
Main unit
Rated Capacity (HP), (only for combinable type)
Cooling Capacity (×100W)
Water source type
Midea VRF
Series code
Refrigerant type N1: R410A
Power supply type
V: 220-240V~60Hz
Omit: 220-240V~50Hz
Electrical Auxiliary Heater
D: with EAH
Omit: without EAH
Motor Type
D: DC Fan Motor
Omit: AC fan Motor
Indoor unit type* (refer to below table)
Cooling Capacity (×100W)
VRF Indoor Unit
Midea
