R410A DC Inverter VRF V4 Plus W Series 50Hz MCAC-VTSM-2016-04
168 Specification & Performance
7. Accessories
7.1 Standard accessories
No
Name
Quantity
Purpose
1
Main unit installation manual
1
/
2
Main unit owner’s manual
1
Be sure to deliver it to the customer
3
Indoor unit owner’s manual
1
Be sure to deliver it to the customer
4
User’s guideline
1
Be sure to deliver it to the customer
5
Bolts bag
1
Stone for service
6
Toggling flathead screw
1
For toggling of indoor and main units
7
Water outlet connector
1
For draining the internal condensed water of the unit
8
Water outlet plug
1
Block a drainage port of the unit chassis which do
not need to drainage
9
Seal ring
2
For avoiding water leakage of the chassis
10
Y-shape water filter
1
Connect to the side of water inlet pie
11
Indoor unit branch pipes
installation manual
1
12
Main unit branch pipes installation
manual
1
13
Seal plug
8
For pipe cleaning
14
Connective pipe accessory
1
Connect to the side of liquid pipe
15
Air side connective pipe
1 or 2
Connect to the air pipe side(8/10HP 1pc,12HP 2pcs)
7.2 Optional accessories
Branch joint of outdoor & indoor unit
Optional accessories
Model name
Packing Size (mm)
Gross/net
Weight (kg)
Function
Branch Joint of outdoor
unit
FQZHW-02N1D
255×150×185
1.5/1.2
Distribute the refrigerant to
Indoor Units and balance the
resistance between each
outdoor unit.
FQZHW-03N1D
345×160×285
3.4/2.4
Branch Joint of indoor
unit
FQZHN-01D
290×105×100
0.4/0.3
FQZHN-02D
290×105×100
0.6/0.4
FQZHN-03D
310×130×125
0.9/0.6
FQZHN-04D
350×170×180
1.5/1.1
FQZHN-05D
365×195×215
1.9/1.4
Other optional accessories
Optional accessories
Model name
Function
Outdoor controller
MD-CCM02/E
Monitor the outdoor operating parameter
Three phase electricity power
protector
DPA51CM44
or
HWUA/DPB71CM48
To stop the air-conditioner running in case of bad power
supply such as Phase Error, Over-voltage, Under-voltage
lose, phase lost and phase sequence inverse. Thus to protect
the equipment.
Digital ammeter (WHM)
DTS634/DT636
Electricity Charge monitor
