R410A DC Inverter VRF V4 Plus W Series 50Hz MCAC-VTSM-2016-04
18 Specification & Performance
2. Dimensions
8HP/10HP/12HP (unit: mm)
3. Piping diagrams
Inverter
compressor
Oil separator
ST
EXVB
SV2
SV4
Electronic expansion valve
Electromagnetic valve
Filter
Pressure sensor
Pressure Switch
Way valve
Symbol Description
Temperature probe
SV3
Pressure relief valve
TSC1
TSC2
TSJ
T7
EXVA
