V6-i Series Engineering Data Book
V6-i Series System Commissioning Report – Sheet D
Observed values
DSP1
content
Parameters displayed on DSP2
Remarks
Cooling
mode
Heating
mode
0.--
Unit capacity (Hp)
Actual value = value displayed
1.--
Setting number of indoor units
2.--
Operating mode
Refer to Note 1
3.--
Fan speed index
Refer to Note 2
4.--
Total capacity of outdoor unit
5.--
Total capacity requirement of indoor units
6.--
Main heat exchanger pipe (T3) temperature (°C)
Actual value = value displayed
7.--
Outdoor ambient (T4) temperature (°C)
Actual value = value displayed
8.--
Inverter compressor discharge temperature (°C)
Actual value = value displayed
9.--
Invert module (TF) temperature (°C)
Actual value = value displayed
10.--
Refrigerant cooling pipe (TL) temperature (°C)
Actual value = value displayed
11.--
Compressor discharge pressure (MPa)
Actual value = value displayed × 0.1
12.--
Discharge superheat degree (°C)
Actual value = value displayed
13.--
EXVA position
Actual value = value displayed × 8
14.--
Actual current (A)
Actual value = value displayed
15.--
Inverter compressor current (A)
Actual value = value displayed
16.--
Actual voltage (V)
Actual value = value displayed
17.--
DC bus voltage (V)
Actual value = value displayed
18.--
Indoor heat exchanger pipe (T2/T2B) temperature (°C)
Actual value = value displayed
19.--
Priority mode
Refer to Note 3
20.--
Number of indoor units currently in communication with outdoor
unit
Actual value = value displayed
21.--
Number of indoor units currently operating
Actual value = value displayed
22.--
Most recent error or protection code
“nn“ is displayed if no error or protection
events have occurred since start-up
23.--
Software version
-- --
--
End
Notes:
1. Operating mode:
 0: off; 2: cooling; 3: heating; 4: forced cooling.
2. The fan speed index is related to the fan speed in rpm and can take any integer value in the range 1 (slowest) to 11 (fastest).
3. Priority mode:
 0: heating priority; 1: cooling priority; 2: first ON priority; 3: heating only; 4: cooling only; 5: test mode 1; 6: test mode 2.
