VC Pro VRF 50/60Hz
27
Part 2 - Outdoor Unit Engineering Data
54-58HP
Table 2-1.8: 54-58HP specifications
HP
54
56
58
Model name
MVC-1515WV2GN1
MVC-1570WV2GN1
MVC-1635WV2GN1
Combination type
28HP+26HP
28HP+28HP
30HP+28HP
Power supply
V/Ph/Hz
380-415V 3N~50/60HZ
Cooling
1
Capacity
kW
151.5
157.0
163.5
kBtu/h
517.4
536.2
558.4
Power input
kW
49.48
52.16
55.59
EER
3.06
3.01
2.94
Connected
indoor unit
Total capacity
50-130%
Maximum quantity
64
Compressor
Type
DC inverter
Quantity
4
Oil type
FV 50s
Start-up method
Soft start
Fan
Type
DC
Quantity
4
Motor output
kW
0.56×4
ESP
Pa
20 default;60 customization option
Airflow rate
m3/h
40200
41200
Drive type
20 default;60 customization option
Refrigerant
Type
R410A
Factory charge
kg
19×2
Pipe
connections
2
Liquid pipe
mm
19.1
Gas pipe
mm
38.1
41.2
Sound pressure level
3
dB(A)
66
66
Net dimensions (W×H×D)
mm
(1585×1615×765)×2
Packed dimensions (W×H×D)
mm
(1650×1810×840)×2
Net weight
kg
338×2
Gross weight
kg
362×2
Ambient
temp.
Cooling
o
C
-5 to 55
Notes:
1. Indoor air temperature 27°C DB, 19°C WB; outdoor air temperature 35°C DB; equivalent refrigerant piping length 7.5m with zero level difference.
2. Diameters given are those of the unit's accessories.
3. Sound pressure level is measured at a position 1m in front of the unit and 1.3m above the floor in a semi-anechoic chamber.
