Take o the 4 screws as indicated in Picture 1.
Take o the shell as Picture 1.
Take o the two srews on the proportional valve and gas distributor as indicated in
Picture 2.
Take o the four screws on the burner and gas distributor as indicated in Picture 2.
Take o the gas distributor as Picture 2.
Replace the gas distributor as in Picture 2.
Install the gas distributor. Picture 3.
Put on the shell. Picture 4.
FA /5E parameter adjustment. Picture 5.
●
●
●
●
●
●
●
●
●
Installation/Assembly
Gas distributor
