Installation of water inlet and outlet pipes
Connect the water inlet and outlet pipes and tap water pipe of the unit with an Ф10mm
metal hose, or with a water pipe with an inner diameter of greater than 15mm.
Gas pipe joint
Rubber sealing ring
Hose pipe joint
Work carrier
Gas rubber hose
Water outlet joint
Gasket
Nut
Water outlet pipe
Gas inlet pipe
Water inlet pipe
Water inlet pipe joint
Gas pipe joint
