Midea VRF Service Manual

MCAC-VTSM-2016-05 One-way Cassette
Indoor Unit 11
HP set switch ENC1 definition list
Code
Name
Code
Indoor Unit
Capacity Value
FM
Fan motor
GM
Swing motor
0
1800W(0.6HP)
DM
Water drainage pump
0
2200W(0.8HP)
CS
Water level switch
1
2800W(1.0HP)
PMV
Electronic expansion valve
2
3600W(1.2HP)
T1
Indoor temp. sensor
3
4500W(1.5HP)
T2
Mid-pipe temp. sensor of evaporator
4
5600W(2.0HP)
T2B
Outlet temp. sensor of evaporator
5
7100W(2.5HP)
XP1-3
Butt connection socket
6
8000W(3.0HP)
XS1-3
Butt connection socket
7
9000W(3.2HP)
TR
Power transformer
8
11200W(4.0HP)
9
14000W(5.0HP)
1
The E-heating component is optional, not for all models.
2
All dial code switches (include HP switch) cannot be adjusted by the
user!
3
Power wire fixed screw must be fastened, otherwise may cause fire!
4
After air-conditioner installation and maintenance, put back the electric
control box cover, otherwise may cause fire and electric shock!

Midea VRF Specifications

General

Type	VRF (Variable Refrigerant Flow)
Brand	Midea
Control	Centralized controller, BMS integration, individual remote controllers
Refrigerant	R410A or R32
Indoor Unit Types	ducted, floor standing, wall-mounted, ceiling cassette
Outdoor Unit Noise Level	55-65 dB(A)
Indoor Unit Noise Level	22-45 dB(A) (dependent on model and fan speed)
