Midea VRF Service Manual

Two-way Cassette MCAC-VTSM-2016-05
40 Indoor Unit
10. Accessories
Standard accessories
Name
Quantity
Shape
Purpose
Installation manual for indoor unit
1
Guidance of installation for indoor unit and
Must deliver to customer
Insulation sheath
2
Thermal insulation for the jointing part of
piping
Installation paper board
1
For confirming the ceiling site and unit
location
Installation gauge
1
For confirming the ceiling site (Integrated on
installation paper board)
Installation screw for paper board
4
For installing paper board
Nut
8
Hanging component
Thermal insulated material
1
Thermal insulation for the jointing part of
drain pipe
Bushing
8
Hanger assembly
Flexible hose tube
1
For drain pipe
Thermal insulation material
1
For sealing the jointing part of piping
Remote controller
1
For remove controlling the air conditioner
Mounting screw
4
For installing defrosting tray
Drain pipe clasp
1
For installing drain pipe
Connective pipe for restriction
assembly
1
/
Tightening belt
5
/
