Midea VRF Service Manual

MCAC-VTSM-2016-05 Silent Four-way Cassette
Indoor unit 85
Specifications
Model
MDV-D56Q4/
VN1-E
MDV-D71Q4/
VN1-E
MDV-D80Q4/
VN1-E
Power supply
208-230V~ 60Hz
Cooling
Capacity
kW
5.6
7.1
8.0
Btu/h
19107
24225
27296
Power input
W
88
105
120
Heating
Capacity
kW
6.3
8.0
9.0
Btu/h
21496
27296
30708
Power input
W
88
105
120
Indoor fan motor
Model
YDK26-6SA
YDK37-6SA
YDK37-6SA
Type
AC motor
Brand
Weiling, Tongde
Insulation class
B
Safe class
IPX0
Input
W
80
99
110
Output
W
26
37
37
Capacitor
uF
3
2.5
3.5
Indoor fan
Material
Plastic
Type
Centrifugal fan
Diameter
in. (mm)
18-3/4 (476)
Height
in. (mm)
4-15/16 (125)
Indoor coil
Number of rows
2
Tube pitch(a)×row pitch(b)
in. (mm)
13/16×17/32 (21×13.37)
Fin spacing
in. (mm)
1/16 (1.5)
Fin type
Hydrophilic aluminium
Tube size
in. (mm)
Ф9/32 (7)
Tube type
Innergroove tube
Coil length×height
in. (mm)
80-3/4×6-5/8 (2051×168)
Number of circuits
8
Indoor air flow (H/M/L)
m
3
/h
942/777/662
1235/1013/805
1235/1013/805
CFM
554/457/389
726/596/474
726/596/474
Sound pressure level (H/M/L)
dB(A)
35/31/27
43/37/31
43/37/31
Indoor unit body
Net dimension (W×H×D)
inch
33-1/16×9-1/16×33-1/16
mm
840×230×840
Packing size (W×H×D)
inch
37-19/32×10-1/4×37-19/32
mm
955×260×955
Net/Gross weight
lbs
52.1/63.6
kg
23.7/28.9
Indoor unit panel
Model
T-MBQ4-02B1
Net dimension (W×H×D)
inch
37-13/32×2-9/64×37-13/32
mm
950×54.5×950
Packing size (W×H×D)
inch
40-3/4×3-9/16×40-3/4
mm
1035×90×1035
Net/Gross weight
lbs
13.2/19.8
kg
6/9
Refrigerant type
R410A
Throttle type
Electronic expansion valve
Design pressure (H/L)
MPa
4.4/2.6
Pipe connections
Liquid pipe
in. (mm)
Φ3/8 (9.53)
Gas pipe
in. (mm)
Φ5/8 (15.9)
Drain pipe
in. (mm)
Φ1-1/4 (32)
Controller
Wireless remote controller
Notes:
Capacities are based on the following conditions:
Cooling: Indoor temperature 27°C DB / 19°C WB; Outdoor temperature 35°C DB / 24°C WB.
Heating: Indoor temperature 20°C DB / 15°C WB; Outdoor temperature 7°C DB / 6°C WB.
Piping length: Interconnecting piping length is 7.5m, level difference is 0m.
Sound values are measured in a semi-anechoic room, at a position 1.4m downward from the unit center.
