MCAC-VTSM-2016-05 One-way Cassette
Indoor Unit 7
MDV-D45Q1/VN1-D MDV-D56Q1/VN1-D MDV-D71Q1/VN1-D
53-5/32(1350)
41-1/2(1054)
2-3/4(70)
19-7/8(505)
8-31/32(228)
41-49/64(1061)
7-7/16(189)
63/64
(25)
45-5/8(1235)
11-13/16(300)
11-13/16(300)
45-5/8(1235)
4-11/16(119)
1-21/32(42)
2-23/32(69)
2-23/64(60)
6-11/16(170)
2-61/64
(75)
1-3/16
(30)
3-5/16(84)
2-13/64(56)
1-19/64(33)
2-1/64(51)
4-49/64(121)
17-51/64(452)
Please use the installation paper plate to make sure the position of the installation screws.
Ceiling cutting size:C
Ceiling cutting size:
A
Screw fixing size:D
Please use the installation paper plate to make sure the
positions of the installation screws.
Screw fixing size:B
4×Φ10
Model
No.
18-36
45-71
A
16-59/64(430)
18-1/2(470)
B
11-27/64(290)
11-13/16(300)
C
43-5/16(1100)
50-25/32(1290)
D
39-61/64(1015)
48-5/8(1235)
