2.12 ARP MODE
When the “ARP” is ON, “ARP” LED light Green.
 UP: Up mode, the arpeggiator will play the notes in increasing chromatic order. If
a Cmaj chord is played, the pattern would be: C, E, G, C, E, G, …..
 DOWN: Down mode, the arpeggiator will play the notes in decreasing chromatic
order. If a Cmaj chord is played, the pattern would be: G, E, C, G, E, C, …..
 RANDOM: RANDOM mode, arpeggiator playing notes random broadcast, not
according to the notes in order to play, random play the notes.
 CHRN: Order mode, the arpeggiator will play back the notes in the order that
they were pressed. If the following notes were pressed and held in this order:
C, G, E, B. The output of notes would follow that order and playback: C, G, E,
B, C, G, E, B, C, G, E, B……
 RANGE +: Arpeggiator octave+1，since the default value(1) + 1, a maximum of
4。When the arpeggiator octave is 1，arpeggiator sent two notes. Press the
“RANGE+”， arpeggiator octave+1，the notes add an octave，then sent
three arpeggio notes at the same time。For example, the arpeggiator octave
is 1, sent C2,C3; The arpeggiator octave is 2, sent C2,C3,C4; The arpeggiator
octave is 3, sent C2,C3,C4,C5…….
 RANGE -: Arpeggiator octave-1， a minimum of 1。When the arpeggiator
octave is 2，arpeggiator sent three notes. Press the “RANGE-”， arpeggiator
octave-1，the notes reduce an octave，then sent two arpeggio notes at the
same time。For example, the arpeggiator octave is 1, sent C2,C3; The
arpeggiator octave is 2, sent C2,C3,C4; The arpeggiator octave is 3, sent
C2,C3,C4,C5…….
”SETUP” LED flash Yellow once.
2.13 Arpeggiator time (ARP TIME):
When the “ARP” is ON, ARP TIME---1~1/32: These keyboards are adjust fixed time
for arpeggiator. Arp time: play arpeggiator notes of frequency. Here with the QN said that
if
QN is a crotchets, so are defined as follows:
1 note = QN
1/2 note = (QN/2)
1/4 note = (QN/4)
1/8 note = (QN/8)
1/16 note = (QN/16)
1/32 note = (QN/32)
”SETUP” LED flash Yellow once
