6.12 Drum PAD
Use the mouse to click the Drum PAD, software interface appears translucent red
label, indicating the user can change the Drum PAD custom functions, such as status
byte: TYPE, data bytes: VALUE.
PAD model by PAD MODE change, CHANNEL and KEY CHANNEL to share
6.13 Function of the alias
The area used to display the function of the alias, convenient user to see the alias of
the custom function.
6.14 Modify the alias
User can input function on the edit field alias, note the use of the name to function.
6.15 Data byte (VALUE)
User can click on the "VALUE" on the left side of the square space, fill in 0 ~ 127,
such as the currently selected edit encoder, the “TYPE” select “NOTE”, “VULUE” fill
in 127, the synchronous data to the minicontrol , minicontrol sends a message
format for the encoder (state bytes: 0x90, data bytes: 0x7f, velocity bytes: 0 ~ 0x7f)
6.16 Edit channel (CHANNEL)
Click on the "CHANNEL", the user can choose the encoder, Pusher potentiometers
on the channel (channel value is 0 ~ 15)
6.17 Data type (TYPE)
"TYPE" drop-down box to choose NOTE (0x90), PC (0xc0), PITCH BEND (0xe0),
AFTER TOUCH (0xd0), CC (0xb0);
In the encoder (Data) mode with CC (Relative) and CC (Absolute)
CC(Relative):0xBx （The encoder back to normal mode）;
CC(Absolute):0xBx, Only the encoder (6.11), velocity bytes will enable the absolute
value model, each turn left, velocity bytes will start from 0x40 decreased ; Each turn
right , velocity bytes will start from 0x40 began to increase
6.18 Real-time status information (STATUS,DATA1, DATA2,DEC/HEX)
After connect minicontrol, rotate any potentiometer or encoder and press the button
have information uploaded to the software, according to the real-time STATUS:
STATUS byte (x > 0 x80), DATA1: data bytes (x < 0 x80), DATA2: byte (x < 0 x80),
DEC: decimal, HEX: hexadecimal display
(7) Download MIDI Editor software and firmware update at
http://www.midiplus.com.tw/MIDIPLUS-Download.htm
