2.2 CONTROL FUNCTIONS
Clutch Lever
Engage the tines by bringing the clutch lever to the handle. Releasing
the lever stops the tines and brings the tiller to a stationary position.
Depth Regulator
In hard compacted soil, it helps restrain the tiller’s forward motion. In
looser soil, it controls how deeply the tines can dig into the ground.
Protective Shield
The tiller shield is located in the rear of the tiller and it is used to shield
you from debris being thrown.
ON/OFF Switch
The ON/OFF switch is needed to start and stop the tiller.
Recoil Starter
The recoil starter is attached to the right side of the upper handle. Stand
behind the unit and pull the recoil starter rope to start the unit.
Tines
Tines are rotating metal blades that dig into the soil.
Wheel Assembly
The wheel assembly can be switched between transport mode and
tilling mode.
2.3 MAKE SURE YOU HAVE EVERYTHING
Make sure your tiller has everything listed in the table below.
Part Name Quantity
Tiller 1
User Guide 1
Oil Bottle (500mL) 1
Spark Plug Wrench 1
HH0408
