EL-50332 EV/HEV Battery Service Tool
Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527
www.midtronics.com
10
Chapter 1: Introduction & Overview
Vehicle Interface Module (VIM)
EL-50332-110
Universal Fuse Box
EL-50332-105
High Voltage Interface
Cable (Orange)
EL-50332-120
For connecting the EL-50332 to the
Universal Fuse Box.
VIM Low Voltage Cable (Black)
EL-50332-125
For connecting the EL-50332
to the Vehicle Interface Module
(VIM).
BBDU Low Voltage Interface
Cable (Black)
EL-50332-135
For connecting the Vehicle Interface
Module (VIM) to the hybrid battery
contactor assembly connectors on
an out-of-vehicle battery pack.
TPIM High Voltage Interface
Cable (Orange)
EL-50332-115
APM High Voltage Interface
Cable (Orange)
EL-50332-140
12 Volt Auxiliary Power
Cable (Black)
EL-50332-160
12 Volt Auxiliary To Clamps
Adapter Cable (Black)
EL-50332-165
Sheathed High Voltage Banana
Jack Cable
EL-50332-145
High Voltage Alligator Clamps
EL-50332-170
Black Red
eAssist Cable
EL-50332-130
Spark EV Harness
EL-50332-50
Spark EV OBD-II Harness
EL-50332-60
Spark EV HV Harness
EL-50332-55
