Chapter 6: Utility Menu
EL-50332 EV/HEV Battery Service Tool
The Utility Menu has several functions that you can
use to customize the EV/HEV Battery Service Tool user
interface.
NOTE: If the PIN function is enabled, y ou will need to
enter the 5-digit PIN when accessing the ADMIN func-
tion of the EV/HEV Battery Service Tool.
Clock
The CLOCK ADJUST utility has four settings. Use  or
 to highlight the setting you want to change.
Although the date and time have been set at the factory,
you may want to make adjustments based your time zone or
Daylight Saving Time.
MODE : AM/PM
TIME : 9:07 AM
FORMAT : /DD/MM/YYYY
DATE : 9/26/12
Mode
1. Use  or  to select the MODE and press NEXT to continue.
2. Use  or  to select 24-hour or 12-hour (AM/PM) clock
and press NEXT to continue, or press the corresponding
number key.
1  24 HOUR
2  AM/PM
3. If you used the ARROW keys, press SAVE to save your set-
ting or BACK to return to the CLOCK ADJUST screen with-
out saving the changes.
Time
1. Use  or  to select the TIME and press NEXT to continue.
2. Use  or  to select the hour, minutes, or AM or PM. Use
 or  to adjust the digits.
9 : 07 AM
3. Press SAVE to save your setting, or press BACK to return to
the CLOCK/DATE screen.
Format
1. Use  or  to select the FORMAT and press NEXT to continue.
2. Use  or  to select date format and press NEXT to con-
tinue, or press the corresponding number key.
1  MM/DD/YYYY (month/day/year)
2  DD/MM/YYYY (day/month/year)
3. If you used the ARROW keys, press SAVE to save your set-
ting or BACK to return to the CLOCK ADJUST screen with-
out saving the changes.
Date
1. Use  or  to s elect the DATE and press NEXT to con-
tinue , and press NEXT to continue.
2. Use  or  to highlight the hour, minutes, or AM or PM.
Use  or  to adjust the digits.
9 / 26 / 2012
3. Press SAVE to save your setting or BACK to return to the
CLOCK ADJUST screen without saving the changes.
Shop
The SHOP INFO utility allows you to create a header
for your printed test results showing your business lo-
cation information. The utility’s three (3) information
screens contain 12 lines of text with a maximum of 17
characters per line.
Screen 1 Screen 2 Screen 3
1–YOUR SHOP NAME
—
5–YOUR COUNTRY
—
9–
—
2–1000 ANY STREET 6–YOUR PHONE NUMBER 10–
3–YOUR TOWN, STATE 7–WWW.WEBSITE.CO 11–
4–YOUR POSTAL CODE 8–SHOP ID NUMBER 12–
To create or overwrite a header:
1. Press  or  to highlight the line you want to change.
The cursor will be blinking to the right of the last character
in the line.
2. Press  to move the cursor backward to erase a character.
To move the cursor forward, press .
3. Insert a character by pressing the key associated with the
character as many times as needed.
4. You can center text by selecting blank spaces before and
after lines of text or insert spaces between words.
5. Press SAVE to save your setting or BACK to return to the
SHOP INFO screen without saving the changes.
To help you edit and center your header, use the template in
the Appendix at the back of this manual to lay everything out
before entering it into your tester.
