Midtronics GRX-5100 Quick Training Guide

GRX-5100
Click the tabs at the top and side to view each section
HEV Workstation Cable ConnectionsCharging Process
Universal high voltage
cable (Cable “V”)
High voltage
fuse box
Model specic
low voltage cable
(“See Low Voltage
Cables” tab)
Model specic
high voltage cable
(“See High Voltage
Cables” tab)
120V AC
Cabling Overview
This is an overview of the cable connections for rescue
charging. Note that the high voltage cable that connects
to the vehicle is model-specic.
Cabling
Overview
Verify Frame Wire Ground
Low Voltage
Cable
High Voltage
Cables
Interlock
Cover
The locations of the cable connections to the vehicle
vary by vehicle model. Refer to the repair information
for the vehicle you’re servicing for details on how to
connect the cables to the vehicle.
Battery Charge
Active Test
Toyota NiMH Battery Rescue Charging with the GRX-5100
Quick Training Guide QT015A
16 of 21
©Toyota Motor Sales, U.S.A., Inc., December 16, 2015
