Midtronics JLR EXP-1080 User Manual

Midtronics B.V. Hoofdveste 6 - 8 Houten NL
www.midtronics.com
10
EXP-1080 JLRChapter 3: Test Preparation
Inspecting the Battery
Before starting the test visually inspect the battery for:
• Cracked, buckled, or leaking case. If you see any of these
defects, replace the battery.
• Corroded, loose, or damaged cables and connections.
Repair or replace them as needed.
• Corrosion on the battery terminals, and dirt or acid on
the case top. Clean the case and terminals using a wire
brush and a mixture of water and baking soda.
• Low electrolyte level. If the electrolyte level is too low,
add distilled water to ll up and fully charge the battery.
Do not overll.
• Corroded or loose battery tray and hold-down xture.
Tighten or replace as needed.
Testing Out-of-Vehicle
The preferred battery test location is in the vehicle.
However, if you plan to test out of the vehicle:
• Always disconnect the negative cable from the battery
rst and reconnect it last.
• Always use a carry tool or strap to lift and transport the
battery.
Testing In-Vehicle
The preferred test position is at the battery posts.
At the start of the test, make sure all vehicle accessory loads
are o, the key is not in the ignition, and the doors are
closed. If systems in the vehicle are still active it might lead
to a SYSTEM NOISE message, the tester will automatically
continue to test the battery until the noise is gone.
Connecting the Battery Test Cable
CAUTION: Do not connect the tester to a voltage source
greater than 30 Vdc.
Connect the clamps to the battery: the red clamp to the
positive (+) terminal and the black clamp to the negative (–)
terminal.
If you connect the clamps in the wrong polarity (positive to
negative or negative to positive), the tester displays CLAMPS
REVERSED! Reconnect the clamps correctly.
To make sure both sides of the clamps are gripping the
terminals, rock the each clamp back and forth. A poor
connection will prevent testing, and the tester will display
the message CHECK CONNECTION. If the message
reappears after you have correctly reconnected the clamps,
clean the terminals and reconnect.
Setting User Preferences
Before starting your test you may want to customize the use
of your analyzer by setting preferences in the Utility Menu.
The menu has settings for the display’s date and time, the
contrast and backlight time, a utility to customize printouts,
among others.
To conserve the analyzer’s internal batteries,
the tester will turn o after 30 seconds of inactivity.
Chapter 3: Test Preparation
