EXP-1080 JLRChapter 4: Battery Test
Battery Test Results
After the test the tester will display the battery decisions
with the complete results in a series of screens. Use the UP/
DOWN ARROW keys to scroll through each result. To print
the results press the PRINT softkey. To return to the Main
Menu, press the END softkey.
Battery Decisions and Recommendations
Battery Decisions
Decision Recommended Action
GOOD BATTERY Return the battery to service.
CHARGE & RETEST Fully charge the battery and retest.
Failure to fully charge the battery
before retesting may cause false
readings. If CHARGE REQUIRED
appears again after you fully charge
the battery, replace the battery.
REPLACE BATTERY A REPLACE BATTERY result
may also mean a poor connection
between the battery and the vehicle.
If you tested the battery using the
IN-VEHICLE Test, disconnect the
battery cables and retest using
the OUT-OF-VEHICLE Test before
replacing it.
BAD CELL–REPLACE Replace the battery and retest.
FROZEN BATTERY Thaw the battery and retest.
Battery
decision
Measured
voltage
Selected
rating
Battery
temperature
Measured
CCA
VOLTAGE: 12.79V
MEASURED: 721 A(SAE)
RATED: 760 A(SAE)
TEMPERATURE: 21 °C
SOC: 94%
