Technical Information
42
B 890/B 990
Note:
The plug contacts are sometimes not coded. Take care when replacing the
control electronic to connect the plugs one by one exactly as they were
before. This prevents incorrect connection.
7. Remove the three T20 screws securing the control electronic to the cover.
8. Remove the control electronic.
4.2 Drive Shaft Removal
1. Tilt the ironing table to its horizontal position; see Section 020-4.1.
2. Remove the T20 screw from the rear of the control electronic cover.
3. Lift the cover at the rear and unclip it at the front.
4. Remove the cover/electronic assembly.
5. Remove the roller; see Section 040-4.1.
6. Access the interior side of the frame (where cover was just removed).
7. Remove the E-clip from the end of the drive shaft (next to the gear).
8. Remove the shaft from the gear by pulling the shaft away from the
appliance.
9. Remove the gear from the appliance.
4.3 Bearing Flange Removal
1. Remove the DC motor; see Section 050-4.4.
2. Remove the flange retaining screw (T30) from the motor bracket.
3. Remove the flange.
Note:
Do not apply lubricant when re-installing.
4.4 DC Motor Removal
1. Tilt the ironing table to its horizontal position; see Section 020-4.1.
2. Remove the T20 screw from the rear of the control electronic cover.
3. Lift the cover at the rear and unclip it at the front.
4. Remove the roller; see Section 040-4.1.
5. Access the interior side of the frame (where cover was just removed).
6. Remove the E-clip from the end of the drive shaft (next to the gear).
7. Remove the shaft from the gear by pulling the shaft away from the
appliance.
8. Remove the gear.
9. Remove the 2 T30 screws securing the motor to the frame from outside
the frame. See Figure 050-2.
To Next Page
