Installation
Building in
Take the dividing wall out of the wall
unit.
Secure the support tracks to both
interior walls of the unit using two
3,5 x 16 mm ( 5/8 ") screws, position
as illustrated.
Push the brackets into the slots on
the sides of the cooker hood.
19 mm ( 3/4 ") thick side walls:
16 mm ( 5/8 ") thick side walls:
Fasten the brackets in place on the
cooker hood using the M 6 x 10 mm
hexagonal bolts and washers.
The thickness of the side walls must
be taken into account.
Installation
17
