Page #17 background imageLoading...
Page #17 background image
Before using for the first time
17
Selecting extraction mode or
recirculation mode
The cooker hood is suitable for both
extraction mode and recirculation
mode. The power of the fan is
adapted to suit the selected operating
mode. The cooker hood is delivered
set up for recirculation mode. It has to
be reset for extraction mode.
To reset it for extraction mode, the
operating hours counter for the
charcoal filter(s) has to be deactivated.
Switch off the fan and the lighting.
Press the control and the operating
hours control at the same time.
The charcoal filter symbol and one of
the fan power levels will flash.
Press and hold the control until the
B indicator starts to flash.
Confirm your choice with the
operating hours control.
All the indicator lights will go out.
Extraction mode has now been set.
If you do not confirm your selection
within 4minutes, the cooker hood will
automatically revert to the original
setting.
Setting up Miele@home
Requirements:
- A WiFi network
- The Miele app
- A Miele user account. The user
account can be created via the
Miele app.
Your cooker hood is equipped with an
integrated WiFi module. Connect the
cooker hood to your household WiFi
network. You will then be able to
operate the cooker hood via the Miele
app.
If your Miele hob is connected to a
home WiFi network, you can control the
cooker hood automatically via the
Con@ctivity function.
Before installing the cooker hood in
its final location, ensure that the
signal of your WiFi network is strong
enough.
You can connect to the household WiFi
network via the Miele app or via WPS.

Table of Contents

Other manuals for Miele DAS 4920

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Miele DAS 4920 and is the answer not in the manual?

Miele DAS 4920 Specifications

General IconGeneral
Pressure (Pa)484
Intensive speedYes
Number of speeds3
Type of extractionDucted/Recirculating
Noise level (low speed)37 dB
Maximum extraction power605 m³/h
Noise level (high speed)55 dB
Noise level (medium speed)47 dB
Maximum recirculating power585 m³/h
Minimum distance from gas hob650 mm
Noise level (intensive speed)66 dB
Fluid dynamic efficiency classA
Minimum distance from electric hob450 mm
Current10 A
Connected load90 W
AC input voltage230 V
AC input frequency50 Hz
Energy efficiency scaleA+++ to D
Annual energy consumption22.9 kWh
Bulb typeLED
Bulb power3 W
Illuminance300 lx
Number of bulbs1 bulb(s)
TypeBuilt-in
Cord length1.5 m
Product colorStainless steel
Built-in display-
Exhaust locationTop
Number of filters1 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth273 mm
Width896 mm
Weight14000 g
Depth (max)423 mm
Height (max)436 mm
