Before using for the first time
23
Start WiFi connection on the hob. For
further details, see the hob operating
instructions.
When successfully connected, 2 and 3
will light up constantly.
Quit connection mode on the cooker
hood by pressing the run-on
control.
Con@ctivity has now been activated.
With a direct WiFi connection, it is not
possible to connect the hob and the
cooker hood to a home network.
Should this be required at a later date,
the WiFi connection between the hob
and the cooker hood must be
disconnected (see “Sign out of WiFi”).
Reattempting the connection
If it is not possible to connect, 2 and 3
flash or the cooker hood cancels the
process.
Disconnect the connection to the
cooker hood (see “Signing out of
WiFi”) and to the hob.
Attempt to make the connection
again.

Table of Contents

Other manuals for Miele DAS 4920

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Miele DAS 4920 and is the answer not in the manual?

Miele DAS 4920 Specifications

General IconGeneral
Pressure (Pa)484
Intensive speedYes
Number of speeds3
Type of extractionDucted/Recirculating
Noise level (low speed)37 dB
Maximum extraction power605 m³/h
Noise level (high speed)55 dB
Noise level (medium speed)47 dB
Maximum recirculating power585 m³/h
Minimum distance from gas hob650 mm
Noise level (intensive speed)66 dB
Fluid dynamic efficiency classA
Minimum distance from electric hob450 mm
Current10 A
Connected load90 W
AC input voltage230 V
AC input frequency50 Hz
Energy efficiency scaleA+++ to D
Annual energy consumption22.9 kWh
Bulb typeLED
Bulb power3 W
Illuminance300 lx
Number of bulbs1 bulb(s)
TypeBuilt-in
Cord length1.5 m
Product colorStainless steel
Built-in display-
Exhaust locationTop
Number of filters1 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth273 mm
Width896 mm
Weight14000 g
Depth (max)423 mm
Height (max)436 mm
