Cleaning and care
36
Charcoal filters
With recirculation mode, two charcoal
filters must be inserted in addition to
the grease filter. These are designed to
absorb cooking odours.
The charcoal filters are fitted in the
deflector plate above the grease filter.
Charcoal filters are available to order via
the Miele Webshop, the Miele Spare
Parts Department (see end of this
booklet for contact details) or from your
Miele dealer.
The charcoal filters are listed under
“Technical data” at the back of this
booklet.
Fitting/replacing charcoal filters
The matching frames must be installed
in order to use the charcoal filters.
Follow the directions on the
installation sheet.
 Remove the grease filter from the
cooker hood.
 Remove the charcoal filter packaging.
 Push the charcoal filters into the
frames until they engage firmly.
 Replace the grease filter.
 To remove the charcoal filters, press
the holder clip forwards slightly and
pull the filters down to remove them.

Miele DAS 4920 Specifications

General

Pressure (Pa)	484
Intensive speed	Yes
Number of speeds	3
Type of extraction	Ducted/Recirculating
Noise level (low speed)	37 dB
Maximum extraction power	605 m³/h
Noise level (high speed)	55 dB
Noise level (medium speed)	47 dB
Maximum recirculating power	585 m³/h
Minimum distance from gas hob	650 mm
Noise level (intensive speed)	66 dB
Fluid dynamic efficiency class	A
Minimum distance from electric hob	450 mm
Current	10 A
Connected load	90 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Annual energy consumption	22.9 kWh
Bulb type	LED
Bulb power	3 W
Illuminance	300 lx
Number of bulbs	1 bulb(s)
Type	Built-in
Cord length	1.5 m
Product color	Stainless steel
Built-in display	-
Exhaust location	Top
Number of filters	1 pc(s)

Weight and Dimensions

Depth	273 mm
Width	896 mm
Weight	14000 g
Depth (max)	423 mm
Height (max)	436 mm
