Installation in a tall unit
* Appliances with glass front
** Appliances with metal front
a Steam oven
b Building-in recess
c Inlet for mains connection cable to the appliance
d Recommended position for electrical socket.
Important: Do not position behind the appliance!
e Mains connection cable
Appliance and building-in dimensions
52
455,5
446
549
595
444
22*/23**
75
5
60-568
70
500
448-452
a
b
c
d
e
