Miele HS19 - Wall Mounting the Bracket

Installation and connection
23
Wall mounting
The supplied wall bracket has a mount-
ing plate with a bag of screws attached
to the back.
Attach the mounting plate to the point
on the wall where you want the wall
mounting to be.
 Remove the bag of screws.
 Press the release catch at the bottom
of the wall bracket.
 Remove the mounting plate from the
wall bracket by sliding it downwards.
Attaching the mounting plate
2plugs and 2T20 TORX screws are
supplied for attaching the mounting
plate to the wall.
You will also need a battery-operated
screwdriver or a drill (with a drilling dia-
meter of 6mm).
Depending on how your vacuum
cleaner is configured, select a distance
of 45cm or 98cm between the bottom
edge of the mounting plate and the
floor.
Be careful not to damage any cables
laid in the wall.
