Operation
41
Switching the hob on
 Touch the sensor control.
Further sensor controls will light up.
If no further entry is made, the hob will
switch itself off after a few seconds for
safety reasons.
Switching off a cooking zone/
the hob
Switching the hob off
 To switch off the hob and all the
cooking zones, touch the sensor
control.
Switching off a cooking zone
 To switch off a cooking zone, touch
the relevant cooking zone indicator.
The cooking zone indicator will begin to
flash.
 Touch the 0sensor control on the
numerical display.
Positioning cookware
Refer to the cooking zone data for your
hob model for information about
cookware sizes and the corresponding
positions (see “Familiarisation –
Cooking zone data”).
 Position the cookware as shown
below:
PowerFlex cooking zone
PowerFlex cooking area

Miele KM 7404 FX Specifications

General

Hob type	Zone induction hob
Product color	Black
Hob width size	60 cm
Top surface type	Glass-ceramic
Appliance placement	Built-in
Cooking zone 1 type	Simmer
Cooking zone 4 type	Regular
Cooking zone 1 boost	1700 W
Cooking zone 1 power	1400 W
Cooking zone 2 boost	2500 W
Cooking zone 2 power	1850 W
Cooking zone 4 power	2100 W
Flexible cooking zone	Yes
Cooking zone 1 position	Left rear
Cooking zone 2 position	Left front
Cooking zone 3 position	Right rear
Cooking zone 4 position	Right front
Number of cooking zones	4 zone(s)
Large cooking zone shape	Rectangular
Simmer cooking zone shape	Round
Cooking zone 1 double boost	2200 W
Cooking zone 1 power source	Electric
Cooking zone 2 double boost	3000 W
Cooking zone 3 double boost	3650 W
Cooking zone 3 size (W x D)	190 x 230 mm
Number of gas cooking zones	0 zone(s)
Simmer cooking zone diameter	160 mm
Regular cooking zone diameter	190 mm
Large cooking zone size (W x D)	230 x 390 mm
Number of flexible cooking zones	1 zone(s)
Number of simultaneously used cooking zones	4
Large cooking zone	3400 W
Number of boosters	2
Number of power levels	9
Control type	Touch
Control position	Top front
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Connected load (gas)	0 W
Connected load (electric)	7300 W

Weight and Dimensions

Depth	492 mm
Width	592 mm
Weight	11000 g
Cord length	1.4 m
Height under worktop	51 mm
Installation compartment width	596 mm
Installation compartment depth (max)	496 mm
Installation compartment depth (min)	470 mm
