Control panel
Sensors
a For switching the cooktop on or off
b For setting the power settings
c Safety lock
d For selecting the cooking zones
Check/Refill indicators
f Safety lock
Cooking zone display
g
0 = Cooking zone ready for use
1 to 9 = Power settings
# = Residual heat
F = Fault (see "Safety switch-off")
A = Auto heat-up when the power setting range has been extended
h Indicator lamp for Auto heat-up or extended power setting (see "Programming"),
e.g. the rear right cooking zone
Guide to the appliance
5
c
g
d
a
b
h
