Removing the transit fitting
^ Unscrew the 4 outer screws marked
A completely.
^ Unscrew the 4 screws marked B.
These screws must then be left on
the transit bars.
^
Remove the transit bars.
^ Plug the 4 large holes with the caps
supplied.
The transit fitting together with
screws should be stored in a safe
place for future use. It must be re-fit-
ted if the machine is to be moved
again.
Re-fitting the transit fitting
To refit the transit fitting reverse the pro
-
cedure described above.
Installation
54
