Connection to the drainage
system
The machine drains via a drain pump
with a delivery head of 1 metre.
The drain hose is 1.5 m long. It must
not be kinked as this restricts drainage.
The swivel elbow at the end of the hose
can be turned in either direction, or can
be detached if required, with a sharp
twist and pull.
Drain hose connection:
Direct into a sink: Hook the hose
over the edge and secure. Make
sure that the water can flow freely to
avoid flooding and to prevent water
from being sucked back into the ma-
chine.
Connected to a floor gully.
Connected to a standpipe.
Connected to a plastic drain pipe
with a rubber nipple. There is no
need to use a non-return valve.
If required, the drain hose can be ex-
tended to a length of 5 m. The necess-
ary parts can be purchased from the
Miele Spare Parts Department, or your
Miele dealer.
For a delivery head of more than 1 m
(up to a maximum of 1.8 m) a second
Duo-drain pump is available with the
corresponding conversion kit from the
Miele Spare Parts Department or your
Miele dealer.
Installation
50
