Miele WT 2670 WPM User Manual

,
To avoid the risk of injury the
holes for the transit bars must be
covered after the transit bars have
been removed.
^ Fit the covers on to the two holes.
Then plug the holes as shown with
the caps.
,
The machine must not be moved
without the transit fittings in place.
Store them in a safe place for future
use. They must be re-fitted if the
machine is to be moved again (e.g.
when moving house).
Re-fitting the transit bars
Re-fitting is carried out by reversing the
procedure.
Installation and connection
65

Miele WT 2670 WPM Specifications

General

Door hinge	Left
Loading type	Front-load
Product color	White
Appliance placement	Freestanding
Washing capacity	5 kg
Delay start (max)	24 h
Maximum spin speed	400 RPM
Washing class	A
Water consumption per cycle	65 L
Energy consumption washing per cycle	3.4 kWh
Drum interior light	Yes

Weight and Dimensions

Depth	580 mm
Width	595 mm
Height	850 mm
