Miele WT 2670 WPM User Manual

Connection to the drainage
system
The machine drains via a drain pump
with a delivery head of 1 metre. The
drain hose must not be kinked as this
restricts drainage. The swivel elbow at
the end of the hose can be turned in
either direction, or can be detached if
required, with a sharp twist and pull.
If required the drain hose can be
extended to a length of 5 m. The
necessary parts can purchased from
the Miele Spare Parts Department or
your Miele dealer.
Drain hose connection:
1. Direct into a sink or basin.
Please note the following:
–
Hook the hose over the edge and
secure.
–
Make sure that the water can drain
away freely without hindrance.
Otherwise there is a risk of water
overflowing or of some of the drained
water being sucked back into the
machine.
2. Connected securely to a plastic drain
pipe with a rubber nipple. There is no
need to use a non-return valve.
3. Connected securely to a standpipe.
4. Connected securely to a floor gully.
Installation and connection
73

Miele WT 2670 WPM Specifications

General

Door hinge	Left
Loading type	Front-load
Product color	White
Appliance placement	Freestanding
Washing capacity	5 kg
Delay start (max)	24 h
Maximum spin speed	400 RPM
Washing class	A
Water consumption per cycle	65 L
Energy consumption washing per cycle	3.4 kWh
Drum interior light	Yes

Weight and Dimensions

Depth	580 mm
Width	595 mm
Height	850 mm
