USER’S MANUAL MIG
____________________________________________________________________
____________________________________________________________________________________
MATT di LIEVORE SRL Via Bianche 7 36010 Carre’ ( VI ) Tel. 0445 / 892223 Fax 0445 / 390346
(**) If comfort is enabled dip 6 don't cares
(***) The function photocell retrigger makes the timing of the pause restart if the
photocells are in use during the pause itself.
After each mode change it is necessary to short circuit JR1 reset contacts for a few
seconds so that the change can take effect)
REGULATIONS
(TR1) DELAY Pause time From 0 to 140 secondi
(TR3) SK - CU Slowing speed From 0 to 100%
The TR1 DELAY trimmer regulates the timing of the pause (the time the gate
remains still before being closed automatically), which varies from 1 to 120
seconds.
The TR2 TORQUE trimmer regulates the torque of the motor. For motors equipped
with a clutch or for oil-pressure motors it is necessary to rotate the TR2 TORQUE
trimmer to the maximum extent possible (i.e., a complete clockwise rotation).
The TR3 SK-CU trimmer regulates the speed at which the timing is slowed, which
can be regulated within the safety parameters. By regulating the TR3 SLACK
trimmer to the maximum extent possible (i.e., a complete clockwise rotation),
the slowing does not take place (see learning procedure without slowing).
The TR4 BRAKE trimmer regulates the brake intensity. To disable the brake it is
necessary to regulate the trimmer to a minimum.
