There are two 5x20-size fuses on the board that protect the 230V line and the
secondary of the transformer.
The fuses have the following values:
230V line F1 = 5 A fast
Secondary F2 = 630 mA fast
Before replacing the fuses it is necessary to turn off the 230V mains power supply. The
power of these fuses must not be modified.
There is no other component on the board that can be repaired or replaced by the
installation personnel.
For any other intervention it is necessary to contact technical support.
SETTINGS
DIP 1 DIP 2 DIP 3 Operating mode
OFF
OFF
OFF
Condominium automatic
OFF OFF ON Condominium automatic + Comfort (*)
OFF ON OFF Superautomatic
OFF
ON
ON
Superautomatic + Comfort (*)
ON ON OFF Automatic
ON ON ON Automatic + Comfort (*)
ON
OFF
OFF
Semiautomatic
ON OFF ON Step by step
DIP Function ON OFF
4
Preflashing
Enabled
Disabled
5
Flash light type
With board
Lamp only
6 Photocell retrigger(***) Enabled (**) Disabled (**)
DIP 7
DIP 8
Installation type
OFF
OFF
SLIDING GATES
(*) The function comfort enables the gate to be closed 5 seconds after the
photocells have received a pulse, regardless of the timing of the pause setting.
