CONNECTION M4
1 + LOCK OR LBC Active during opening/closing, fixed if boom stopped
2
- LOCK OR LBC
3 + FLASH Flashing during opening/closing, if DIP 1 ON preflashing, 3 sec before any action
4 - FLASH
5 + M1 Motor
6
- M1
CONNECTION M3
1 GND antena
2
+ ANTENNA
CONNECTION CN2
1 S1 Sec 1 trasformatore 22 V
2 0 com trasformatore 0 V
3
S2
Sec 2 trasformatore 22 V
