Migatronic MIG 445 MK III User Manual

16
TECHNICAL DATA
TECHNICAL DATA MIG MK III We reserve the right to changes
Type MIG 385C MIG 445C MIG 385S MIG 445S MIG 545S Unit
Fuse 230 V 25 40 25 40 50 A
Fuse 400 V 16 25 16 25 35 A
Efficiency 0.77 0.71 0.77 0.71 0.74
Cos phi 0.99 0.99 0.99 0.99 0.99
Open circuit voltage 17-43 18-51 17-43 18-51 17-57 V
Voltage position 24 24 24 24 36 pcs
100% duty cycle (40°C) 240 265 240 265 350 A
60% duty cycle (40°C) 300 315 300 315 430 A
35% duty cycle (40°C) 335 405 335 405 505 A
Current range min. 40A/16V 40A/16V 40A/16V 40A/16V 40A/16V A/V
Current range max. 385A/28.8V 445A/36.3V 385A/28.8V 445A/36.3V 545A/41.3V A/V
Inductance positions 2 2 2 2 4 pcs
1
Protection class IP21 IP21 IP21 IP21 IP21
2
Sphere of application
S S S S S
Standards EN/IEC60974-1
EN/IEC60974-2
EN/IEC60974-5
EN/IEC60974-10 (Class A)
Cooling system (optional) 3.5 L 3.5 L 3.5 L 3.5 L 3.5 L L
Cooling 700 700 800 800 800 W
Wire feed motor effect 100 100 W
Wire reel capacity up to 300 300 mm
Wire dimension 0.8-1.6 0.8-1.6 mm
Wire speed 1.3-18 1.3-18 m/min
Mode switch 2T/4T/Spot 2T/4T/Spot mode
Pre-flow 0.2 0.2 sec
Soft-start 0-4 0-4 m/min
Burn-back 0.05-0.5 0.05-0.5 sec
Post-flow 0-10 0-10 sec
Dim. lxbxh 94x51x84 94x51x84 94x51x84 94x51x84 94x51x84 cm
Total weight (without MWF) 135 163 132 160 201 kg
1
Indicates that the machine cannot be used outside in the rain
2
S
The machine meets the standards which are demanded of machines working in areas where there is an increased risk of
electric shock
