CABLE INSTALLATION
Before the installation and use, please read carefully the relevant content in “Notice for Maintenance and
Safety”.
1. Take the LCD TV from the wrapping package and put it in a drafty and flat place.
NOTE: When y
ou plug or unplug the LCD TV, computer or other equipments, you must make
sure that the AC power has been already shut down;
When unplugging the power cable or signal cable, please hold the plug (the insulated
part), do not draw the body of the cable.
2. The RF output terminal can be connected with the RF input port of the TV.
3. The output AV/S-VIDEO terminal of DVD can be connected with the AV/S-VIDEO input port of
the TV
through AV/S-VIDEO cable.
4. The output COMPONENT(YPbPr) terminal of DVD can be connected with the COMPONENT(YPbPr)
input port of the TV through AV cable.
5. Connect one end of the VGA cable with the VGA port
on computer, connect the other end of the VGA
cable with the VGA port on the TV, and tighten the bolts clockwise on the each end of VGA cable.
NOTE: While connecting the 15-pin
VGA, please do not insert the plug overexertedly, for fear
the pin might be broken.
6. Connect one end of the HDMI cable
with HDMI output port, connect the other end of the HDMI cable
with the HDMI port on the TV.
NOTE: While connecting the HDMI, please aim at carefully
, do not insert overexertedly, for
fear the pin might be broken.
7. The AV
output of the TV can be connected with the input port of other AV equipment through AV cable.
8. Check and make sure that all AV cables are connected with the corresponding po
rts correctly.
9. Connect the AC power
cable with 100-240V AC power supply.
NOTE：
The range of power input for the LCD TV is 100-240V/50Hz, 60Hz, do not connect the
AC power cable with the AC power out of the above range.
Please hold the insulated part of the plug when you are unplugging the power cable,
do not touch directly the metallic part of the cable.
5
