MikroTik hAP lite User Manual

1.
2.
3.
4.
5.
6.
Scan QR code and choose your preferred OS.
Install and open application.
By default, the IP address and user name will be already entered.
Click Connect to establish a connection to your device through a wireless network.
Choose Quick setup and application will guide you through all basic configuration settings in a couple of easy steps.
An advanced menu is available to fully configure all necessary settings.
Powering
The device accepts power in the following ways:
microUSB accepts 5 V DC.
The power consumption under maximum load can reach 5 W.
Configuration
Once logged in, we recommend clicking the "Check for updates" button in the QuickSet menu, as updating your RouterOS software to the latest version
ensures the best performance and stability. For wireless models, please make sure you have selected the country where the device will be used, to
conform with local regulations.
RouterOS includes many configuration options in addition to what is described in this document. We suggest starting here to get yourself accustomed to
the possibilities: . In case IP connection is not available, the Winbox tool ( ) can be used to connect to the MAC address https://mt.lv/help https://mt.lv/winbox
of the device from the LAN side (all access is blocked from the Internet port by default).
For recovery purposes, it is possible to boot the device for reinstallation, see section .Buttons and Jumpers
Mounting
The device is designed to be used indoors and placed on a flat surface with all needed cables connecting to the front of the unit.
Alternatively, unit can be mounted on the wall, mounting points are located on the bottom side of the device, screws are not included in the package.
Screws with size 4x25 mm fit nicely, depending on your wall structure you can use dowels 6x30 mm and 6 mm drill bit if needed.
When mounting on the wall, please ensure that cable feed is pointing downwards.
The IP rating scale of this device is IPX0. We recommend using Cat6 shielded cables.
Warning! This equipment should be installed and operated with a minimum distance of 20 cm between the device and your body. Operation of this
equipment in the residential environment could cause radio interference.
Expansion slots and ports
Four 10/100 Ethernet ports, supporting automatic cross/straight cable correction (Auto MDI/X). Either straight or crossover cable can be used for
connecting to other network devices.
Integrated wireless module 2.4 GHz, 802.11b/g/n, antenna gain 1.5 dBi.
Reset button
RouterBOOT reset button has the following functions. Press the button and apply the power, then:

MikroTik hAP lite Specifications

General

2.4 GHz	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	32 MB
Processor model	Qualcomm Atheros QCA9531
Processor frequency	650 MHz
Product color	White
Ethernet LAN (RJ-45) ports	4
Wireless standard	802.11b/g/n
AC input voltage	5 V
Power consumption (max)	3 W
Antenna features	Integrated antenna
Antenna gain level (max)	1.5 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	89 mm
Width	113 mm
Height	28 mm
