2.
Continued
:
MY
30
Only
:
Take the combustion air inlet silencer and fix to the front of the heater s
/
s mounting bracket with the
cable ties provided
.
Cut the black combustion air tube to length and fix to the silencer and the heater with the two
32
mm hose clips
.
3
.
Fuel system:
The heater is supplied with a fuel standpipe to be fitted into the top of the fuel tank
.
Use this wherever possible
-
it is
the preferred method because it does not interfere with the engine fuel supply
.
Find a suitable location in the fuel tank that has no obstructions inside
,
put some grease around the chosen location
and drill a
22
mm hole
-
the grease should help prevent any debris falling into the fuel tank
.
Now cut the standpipe so
that it is about
30
mm off the bottom of the fuel tank
,
slide into place and tighten the fixing nut
. (
see dia
3
.)
NOTE
:
The fuel pump is a solenoid which is pulsed by the control box
-
be careful not to mount it on a board that may
resonate
.
If after installation the pump is noisy re
-
locate it
!
Installation of copper fuel line
.
1
.
Fit the
1/4
"
to
3/
16
"
reducer onto the standpipe
.
2
.
Cut the required length of copper pipe from the
amount supplied and fit to the fuel cock
.
3
.
Fit the straight connectors to the fuel pump
.
NOTE
:
3
connectors are fitted with 1
rubber olive and
1
copper
olive and
1
straight connector is fitted with 2 rubber
olives
.
The connector with
2
rubber olives is to be mounted
between the fuel pump outlet and the fuel damper
.
Item
'A'.
4
.
Mount the fuel pump near the fuel cock at a
45
o
angle as shown
.
5
.
Fix the remaining connector to the fuel inlet on the
heater with the rubber olive on the heater stub
.
6
.
Cut the copper pipe to length
,
fit to the pump and the
heater
.
30mm
Diesel
tank
Heater
.
Fuel standpipe
1/4
"
x
3/
16
"
Reducer
3/
16
"
Fuel cock
Fuel pump
.
These olives are
neoprene rubber
.
The fitting on the heater uses a
neoprene rubber olive
'A'.
Length of pipe
(
max
)
Standpipe to fuel pump
:
Fuel pump to heater
:
Head
(
max
)
Bottom of fuel tank to pump
centre
:
Pump centre to heater centre
:
(
mm
)
2000
5000
1000
<
2000
-
3
-
Dia
3.
