Mounting Control Box on Tiebars
1. Mount the control box to mounting brackets using 10 mm wrench (Fig 2-8)
2. Mount control box on the tie bars by attaching front end first and pushing down to snap in the back end (Fig. 2-9)
3. Locate the two extra pieces for the tie bars mounting brackets (Fig. 2-10)
4. Screw in these pieces to the rear side of the tie bar bracket using a Philips Head Screw Driver (Fig. 2-11)
Fig. 2-8
Fig. 2-10
Fig. 2-9
Fig. 2-11
2121 Blount Road Pompano Beach, FL 33069 MileMarker.com 1.800.886.8647 PAGE 6
