Milesight UR35 - Hardware Introduction; Device Overview; Device Dimensions

UR35 Quick Start Guide
www.milesight-iot.com
4
2. Hardware Introduction
2.1 Overview
A. Front Panel
B. Left Side Panel
7 Grounding Stud
8 SIM and Reset Button Holder
9 Power Connector
10 Serial Port & I/O
2.2 Dimensions (mm)
1 Wi-Fi Antenna Connector
2 AUX Antenna Cellular Connector
3 GPS Antenna Connector
4 MAIN Cellular Antenna Connector
5 LED Indicator Area
POWER: Power Indicator
SYSTEM: Status Indicator
Wi-Fi: Wi-Fi Indicator
VPN: VPN Indicator
SIM : SIM Status Indicator
: Signal Strength Indicator
6 Ethernet Port & Indicator
