ETHOS EZ User manual MA073-006 Terminal chapter Page - 44 -
OPERATING PROGRAM (press PREP)
Recall a control program.
Application methods can be developed and several different
processes can be accomplished, like for example pressure reactions,
syntheses, combinatorial chemistry processes, extractions, etc.
The program adapts to different conditions, e.g. number of
samples, sample quantity, sample volume in case of liquids, over an
automatic power adjustment.
General Operating Instructions
The screen surface may look different depending on which components are installed
and have been activated in the system administration.
Software is operated via Touch-Screen. Touching the screen the different switching surfaces
or input fields are activated. Clicking with the mouse will produce the same effect.
The activated input fields are ready for input over a keyboard. Double-touching the activated
field a numeric or standard keyboard will appear on the screen.
Some symbols/icons are present in each menu (or are generally used). They are
described in the following chapter.
Symbols/icons that are present only in certain menus are described in their respective
dedicated chapters.
Generally Used Icons
OPEN FILE
This will open the file listing to enable user to select and open a file.
SAVE FILE
It will open the file listing where the current file can be saved. A
name must be assigned to the file to be saved.
PRINT FILE
It will print out reports or diagrams.
GO BACK
The operating program is quitted and will go back to the start
screen.
