Section 7: Basic Operation
1. Insert one end of the DP cable to the graphics card in your PC. Other types of connection can be
used. additional cables not included.
To refresh rate (or "performance") is ideal, it is suggested to use a cable DP (Display Port) or
HDMI monitor with the mating connector.
2. Connect the other end of the cable into the monitor corresponding connector. See the image
below.
Audio Output Connector
Powe
r Connector
3. Connect the power cable to the monitor and connect the other end to your power source. It is
recommended to use a surge protector with proper tension when a wall outlet is not directly
accessible.
4. Locate the on / off button on the monitor and press it to turn on the monitor.
AMD FreeSync
The feature is enabled by default. To use this feature, please note that you must have a material
capacity FreeSync, a DP cabl
e and the latest graphics drivers. To use this function, connect your
computer and monitor with a DP cable. After connecting, you might receive a message to activate
the function on your computer. If you do not receive the message, you may need to activate the
function in the menu of your graphics card. See the documentation from the manufacturer of your
graphics card for instructions on enabling FreeSync.
Section 8: Indicator Light
Indicator light
A s
olid blue light indicates the monitor is turned on and functioning normally. A flashing blue light
indicates that no video source is detected. Please ensure that your computer is on and that all video
cables are fully inserted and / or connected.
HDMI ConnectorsDP Connectors
EN-15
