5. Adjust the Touch velocity for the pads using the rotary control [–] / [+] (Linear, Exp1,
Exp2, Log1, Log2, Spline).
6.
Activate the next pad or use [PAGE] to select another desired setting parameter.
If several pads are mounted on a rack vibrations can be transmitted to other pads when you hit
a trigger and unintentionally trigger sounds. Crosstalk can be prevented by the temporary sup‐
pression of the trigger signal. This parameter is set automatically in the setup menu.
1. Press [SETUP].
2.
Use [PAGE] to select the menu item ‘Advance’.
3. Press [ENTER] to open the Advance menu.
ð
Use [PAGE] to switch to the setting parameter ‘Xtalk’.
4. Play any pad until you hear only the sound of this pad.
ð
The module automatically detects the vibration and compensates it while striking
the installed pads.
Here you can specify the note value for each pad to be used for sending MIDI data to external
devices.
Crosstalk
Note Send
Operating
MPS-500 USB
41
