SECTION 4 − SPECIFICATIONS
4-1. Serial Number And Rating Label Location
The serial number and rating information for this product is located on the back of unit. Use rating label to determine input power requirements and/or
rated output. For future reference, write serial number in space provided on back cover of this manual.
4-2. Software Licensing Agreement
The End User License Agreement and any third-party notices and terms and conditions pertaining to third-party software can be found at
https://www
.millerwelds.com/eula
and are incorporated by reference herein.
4-3. Information About Default Weld Parameters And Settings
NOTICE − Each welding application is unique. Although certain Miller Electric products are designed to determine and default to certain typical welding
parameters and settings based upon specific and relatively limited application variables input by the end user, such default settings are for reference
purposes only; and final weld results can be affected by other variables and application-specific circumstances. The appropriateness of all parameters
and settings should be evaluated and modified by the end user as necessary based upon application-specific requirements. The end user is solely
responsible for selection and coordination of appropriate equipment, adoption or adjustment of default weld parameters and settings, and ultimate
quality and durability of all resultant welds. Miller Electric expressly disclaims any and all implied warranties including any implied warranty of fitness
for a particular purpose.
4-4. Unit Specifications For MIG (GMAW)
. Do not use information in unit specifications table to determine electrical service requirements. See Sections 5-2 and 5-3 for information on con-
necting input power.
. This equipment will deliver rated output at an ambient air temperature up to 1045F (405C).
Rated Welding
Output
Amperage Range
Maximum Open-
Circuit Voltage DC
Amperes Input At Rated Load Output, 50/60 Hz, Single Phase
240 VAC
235 A, 25.8 volts DC,
20% Duty Cycle
30−235 A 54 31.2
170 A, 22.5 volts DC,
60% Duty Cycle
30−235 A 54 19.9
Wire Type And Diameter Wire Feed Speed
Solid Steel
0.024 − 0.035
Flux Cored
0.030 − 0.045
Aluminum
0.030 − 3/64
50−600 IPM
(1.5−15.2 mpm)
4-5. Unit Specifications For Stick (SMAW)
. Do not use information in unit specifications table to determine electrical service requirements. See Sections 5-2 and 5-3 for information on con-
necting input power.
. This equipment will deliver rated output at an ambient air temperature up to 1045F (405C).
Rated Welding
Output
Amperage Range
Maximum Open-
Circuit Voltage DC
Amperes Input At Rated Load Output, 50/60 Hz, Single Phase
240 VAC
200 A, 28 volts DC,
30% Duty Cycle
30−200 54 28
150 A, 26 volts DC,
60% Duty Cycle
30−200 54 20.2
4-6. Unit Specifications For TIG (GTAW)
. Do not use information in unit specifications table to determine electrical service requirements. See Sections 5-2 and 5-3 for information on con-
necting input power.
. This equipment will deliver rated output at an ambient air temperature up to 1045F (405C).
Rated Welding
Output
Amperage Range
Maximum Open-
Circuit Voltage DC
Amperes Input At Rated Load Output, 50/60 Hz, Single Phase
240 VAC
210 A, 18.4 volts DC,
40% Duty Cycle
20−210 54 20.4
180 A, 17.2 volts DC,
60% Duty Cycle
20−210 54 17
To Next Page
