Pellicon
®
Single-Pass TFF
Installation
Pellicon
®
2 Mini Cassette Installation
Required Equipment
Items listed in this table are required for a three-section single-
pass TFF installation with Pellicon
®
2 Mini Cassettes. Sections may
be added or removed as needed for each specific application.
Item Description Quantity
Pellicon
®
Single-Pass TFF Mini Kit
(includes four diverter plates and two silicone gaskets)
1
Pellicon
®
2 Mini Cassette (includes two silicone gaskets) 3
Pellicon
®
Mini holder with extended tie rods 1
NOTES
Refer to the Pellicon
®
2 Cassette Installation Guide for cassette
installation instructions.
Install only identical cassettes in the filter holder. Do not mix
cassettes with different screens, membrane types, filtration
areas, or nominal molecular weight cutoffs.
Installation of Pellicon
®
2 Mini Cassettes requires inter-
cassette gaskets. Each cassette is provided with two gaskets.
The Pellicon
®
Single-Pass TFF Mini Kit provides two additional
gaskets, all of which are required for installation.
The diverter plates must be installed between individual
cassettes with the port locations alternating position as
shown in the following illustration.
