Pellicon
®
Single Pass TFF Accessories Installation and User Guide 15
Pellicon
®
3 0.57 m
2
or 1.14 m
2
Cassette
Installation
Required Equipment
Items listed in this table are required for a three-section single-
pass TFF installation with Pellicon
®
3 0.57 m
2
or 1.14 m
2
Cassettes.
Sections may be added or removed as needed for each specific
application.
Item Description Quantity
Pellicon
®
Single-Pass TFF Cassette diverter plate 3
Pellicon
®
Single-Pass TFF Cassette retentate
collection plate
1
Pellicon
®
3 0.57 m
2
or 1.14 m
2
Cassette 3
Pellicon
®
3 manifold adapter plate 1
Pellicon
®
stainless steel holder 1
NOTES
Refer to the Pellicon
®
3 Cassette Installation Guide for
cassette installation instructions.
Install only identical cassettes in the filter holder. Do not
mix cassettes with different screens, pore sizes or nominal
molecular weight cutoffs.
The single-pass TFF installation with Pellicon
®
3 0.57 m
2
or
1.14 m
2
cassettes requires one Pellicon
®
2 inter-cassette
gasket or one Pellicon
®
3 Manifold adapter plate, which must
be ordered separately.
The Pellicon
®
Single-Pass TFF Cassette retentate collection
plate is required to collect the retentate from the single-pass
TFF cassette installation.
The diverter plates must be installed between individual
cassettes with the tab locations alternating as shown in the
following illustration.
